25.6V12Ah 8S2P LiFePO4 Hnub Ci Tracker roj teeb
• Kev them nyiaj kub: 0 degree ~ 60 degree
• Tshem tawm qhov kub thiab txias: -20 degree ~ ntxiv rau 60 degree
• Qauv nab npawb: ST24-12
• Dimension (L * W * H): 205 * 75 * 110 mm
Hauj lwm lawm
Taw qhia
Hnub ci tracker roj teeb yog LiFePO4 roj teeb los muab lub zog rau lub hnub ci vaj huam sib luag tracker. Lub hnub ci taug qab qhov system yog ib qho cuab yeej siv los tswj lub hnub kom lub ntsiab qhov muag pom ntawm lub zog khaws cia ib txwm sib npaug rau lub hnub rays. Nws yog ib txwm tsom rau lub hnub txij hnub sawv ntxov mus txog hnub poob los txhim kho kev siv lub hnub ci zog. Cov txheej txheem ntawm lub hnub ci tsis siv neeg tracker suav nrog xov tooj cua thiab TV nrhiav thiab taug qab raws li cov lus qhia txhua hnub. Txoj kev taug qab kawg tuaj yeem muab faib ua dual axis taug qab thiab ib qho axis taug qab.
Peb muab cov qauv hnub ci tracker roj teeb (-20 degree ~ 60 degree) thiab dav kub hnub ci tracker roj teeb (-40 degree ~ 60 degree ). Peb muaj LiFePO4 roj teeb 26650 hlwb scheme thiab 32700 hlwb scheme rau cov qauv hnub ci tracker roj teeb.
Khoom Paub meej
Cell qauv: IFR32700-6000
LiFePO4 roj teeb Cell: 3.2V 6AH cylindrical LiFePO4 cell
Cov khoom siv roj teeb: PVC Shrink
Tsim compact: Built-in BMS
OEM hom: Txais
Ntawv pov thawj: CE, UN38.3
Lub sij hawm xa tuaj: hauv 21 hnub
Muaj peev xwm muab khoom: 10000 pcs / hnub
Yam khoom qauv | ST 24-12 |
Hom roj teeb | LiFePO4 |
Nominal voltage | 25.6V |
Nominal Peev Xwm | 12 Aw |
Muaj peev xwm siv tau | 307.2 wb |
Qhov ntev | 205 * 75 * 110 hli |
Qhov hnyav | 2.5 Kg |
Kev them nqi hluav taws xob | 28.4V-29.2V |
Kev them nyiaj tam sim no | 2.4A |
Discharge Voltage | 18.4 V-20V |
Tshem tawm tam sim no | 2.4A |
Peak Discharge Current | 1 0.0A (5ms) |
Hlau & Connector | Raws li kev xav tau |
Kev them nyiaj kub | 0 degree ~ 60 degree |
Tshem Tawm Kub | -20 degree ~ 60 degree |
Cia Kub | -20 degree ~ 45 degree |
Lub neej voj voog | ＞2000 (25 degree 80 feem pua DOD＠0.2C) |
Tsim Lub Neej | 5 xyoos (25 degree) |
Daim ntawv pov thawj | CE / UN38.3 |
Daim ntawv thov
• Hnub ci vaj huam sib luag tracker
• Hnub ci roj teeb system
Nta
(25.6V12Ah 8S2P LiFePO4 Hnub Ci Tracker Roj Teeb)
• Ntau tshaj 5 xyoo kev pab cuam lub neej
• Intelligent roj teeb tswj qhov system (BMS)
• Me me thiab hnyav dua, yooj yim installation
• Kev ua haujlwm siab & qis qis dua
